7KW 32A Wallbox Electric Car Charger GB/T For Home Use Ev Car Ocpp Ev Charger
Features
· The national standard 7-hole connection plug is suitable for charging almost all national standard new energy Vehicle
· Support 0-16A and 0-32A charging current, up to 7kW high-power charging, compatible with 3.5kW and 7kW different types of vehicles
· The whole machine adopts IP55-level rainproof and dustproof design, which can be used stably indoors and outdoors,
and calmly copes with harsh environments
· Encrypted swipe charging design, swipe to unlock charging, prevent theft, safe and worry-free. (Swipe card with screen version)
· Embedded emergency stop mechanical switch design, can be pressed in an emergency to quickly cut off the power supply, increased equipment control safety
Product parameters
| Product Name | 7KW 32A Wallbox Electric Car Charger GB/T For Home Use Ev Car |
| Maximum output power | 7kWA |
| Input voltage | AC 220V |
| Frequency | 50Hz±1Hz |
| Output voltage | AC 220V |
| Output Current Range | 0~16A/0~32A |
| Insulation resistance | ≥ 10MΩ |
| Control module power consumption | ≤7W |
| Working ambient temperature | -25°C~+50°C |
| Storage temperature | -40°C~+70°C |
| Ambient humidity | 5% to 95% no frost, no condensation |
| Altitude | not more than 2000 meters |
| Protection class | IP54 |
| Charging interface | GB 7-hole plug |
| Communication mode | RS485/RS232 (reserved Ethernet, GPRS) |
| Display | 4.3 inch LCD color screen |
| Status indication | LED indicator |
| Weight | ≤6kg (including gun line) |
Packing&Shipmet
FAQ
Q1: What is your terms of packing of EV Charging point?
A: We pack our EV Charging Point in cartons.
Q2: What's the MOQ?
A: Most of our products are in stock,no MOQ.If you have customized requirements, please contact us. We will provide specific solutions for your requirements.
Q3: Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q4: What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q5: Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
